Agilent Varian DS 102

$2,480.00

Part Id: 6700596

Very simple and highly reliable design, the Agilent Varian DS 102 Vacuum Pump is field proven to provide excellent vacuum performance. The DS Rotary Vane pumps provide high pumping stability for light gases, low noise, low operating temperature, minimal oil backstreaming, and a long operating life. Includes anti-suckback valve and vent device, with forced oil circulation.

Request a Quote

Product Description

Very simple and highly reliable design, the Agilent Varian DS 102 Vacuum Pump is field proven to provide excellent vacuum performance. The DS Rotary Vane pumps provide high pumping stability for light gases, low noise, low operating temperature, minimal oil backstreaming, and a long operating life. Includes anti-suckback valve and vent device, with forced oil circulation.

Product Specifications

Ultimate Vacuum

2.0 x 10-3 Torr

Pumping Speed

3.5 CFM

Water Vapor Capacity

100 g/h

Inlet Connection

KF25

Outlet Connection

KF25

Electrical

50/60Hz, AC, 1Ø

Voltage

100V-230V

Warranty

Manufacturer's Warranty
